    SAE 100 R12 1/4 Inch 3/4inch Suction Steel Wire Braided Hydraulic Hose Pipe

    Ask Lasest Price
    Brand Name : Kelong
    Model Number : SAE 100 R12
    Certification : ISO9001 / IRIS
    Payment Terms : L/C, T/T, Paypal
    Supply Ability : 16,5600 meters /months
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    SAE 100 R12 1/4 Inch 3/4inch Suction Steel Wire Braided Hydraulic Hose Pipe

    SAE 100 R12 1/4 Inch 3/4inch Suction Steel Wire Braided Hydraulic Hose Pipe With Oil Resistant Tube

    Application:
    This hose is suitable for delivering petroleum-based hydraulic oils and it is mainly used in high pressure working conditions.

    Features:
    1, Good resistance to oil
    2, Good resistance to extremely high pressure.
    3, Good resistance to abrasion, corrosion, weather, ozone, cut, aging and sunlight.

    Material:
    Tube: high quality black oil resistant synthetic rubber.
    Reinforcement: four layers of high tensile and high strength thick spiraled steel wire in alternating direction.
    Cover: high quality abrasion, weather and corrosion resistant synthetic rubber.
    Working temperature range: -40 °C to +121 °C.


    Specifications:

    1. Oil&weather resistant rubber
    2. Steel wire braided or spiral
    3. High pressure,good flexible
    4. SAE&DIN&EN standard


    CommoditySpecification
    SAE 100R1,R2,R6,R7,R8,R9,R12,R13,R14,R15,R16,R17
    DIN EN8531SN,2SN,1ST,2ST
    DIN EN8564SH 4SP
    DIN EN8571SC,2SC
    SAE 100 R12 steel wire spiraled hydraulic hose
    Hose codeSizeDash
    size
    IDWDODWorking
    pressure
    Proof
    pressure
    Min burst
    pressure
    Min
    bending
    Weight
    mminchminmaxminmaxminmaxMPapsiMPapsiMPapsimmkg/m
    SAE100R12-01103/869.310.116.617.819.521284060568120112162401250.7
    SAE100R12-0212.51/2-812.313.519.921.52324.6284060568120112162401800.83
    SAE100R12-03165/8-1015.516.723.825.426.628.2284060568120112162402001.12
    SAE100R12-04193/4-1218.619.826.928.429.931.5284060568120112162402401.43
    SAE100R12-05251-162526.434.135.736.839.2284060568120112162403002
    SAE100R12-0631.51-1/42031.43342.745.145.448.621304542609084121804202.8
    SAE100R12-07381-1/2-2437.739.349.251.651.95517.5254035507570101505003.4
    SAE100R12-08512-3250.85262.564.865.168.317.5254035507570101506404.25
